Transformer Recycling Machine

Small Transformer Recycling Machine Description

BSGH this model transformer recycling machine is mainly to process all kinds of small transformers. Small transformers mainly refer to single-phase transformers below 20 kV·A and three-phase transformers below 50 kV·A. They are characterized by small size, low cost, and few wires.

The load rate and utilization of small transformers are generally low. The inductive load it carries is generally not capacitively compensated.

Small transformers are common equipment in the electrical control system of factories. With the large-scale application of electronic components in power plants In control, monitoring, and automatic circuits, small transformers are increasingly used. so there's will have more scrap small transformer need to be recycling, then we develop the small transformer recycling machine to process these scrap transformer, cutting and pulling the scrap copper winding from transformers.

Transformer Recycling Machine Structure

Small transformers are composed of two parts: iron core and winding (coil).

(1) Iron core

Commonly used iron cores are E-shaped, Japanese-shaped, F-shaped, and C-shaped. In order to reduce the loss in the iron core, the iron core of the transformer is made of laminated silicon steel sheets. The thickness of the silicon steel sheets is generally 0.35 mm, and a few are 0.5 mm. The surface is coated with an insulating paint and dried or the surface oxide film is used The silicon steel sheets are insulated from each other. The staggered method is usually used when stacking so that the seams of the silicon steel sheets are staggered.

(2) Winding

Commonly known as the coil. Most small transformers adopt a mutual inductance double-coil structure, in which the winding connected to the power supply is called the primary winding; the winding connected to the load is called the secondary winding. The combination of winding and iron core has two types: core type and shell type. For single-phase small transformers, in addition to the C-shaped and other two core structures, the rest of the iron cores are all shell structures; three-phase small transformers usually use E-shaped iron cores to form a core structure. The so-called core structure means that the windings encase the iron core, and the shell structure means that the iron core encases the windings.

Small Transformer Disassembly Recycling Machine Technical Data

Processing Range Of Transformer Recycler Machine:

The maximum size of the four-claw claw opening (wire package outer diameter) is 100MM;

Can also provide customized services according to your actual needs (wire package outer diameter more than 100MM).

Waste Transformer Pictures

Small Transformer Recycling Machine Pictures Show

Transformer Recycling Machine Processing Steps

1.)First, cut the small transformer in half

2.)Secondly, use a machine to pull out the winding set in the small transformer cut in half to separate it from the silicon steel sheet.

3.)Complete recovery of transformer core and winding

BSGH EQUIPMENT Aftersale Service

1: Overseas technical support available.

2: All day long 24hours service, call me: 008613772508206.
